High Current Anti-vandal switch for Marine and Automotive

High Current Anti-vandal switch

19mm diameter panel cutout, Max. rating 21A24VDC, Long life, High reliability, Anti-Vandal IK09/ Sealed IP68, Dot, Ring or Power symbol illumination available, Multiple actuator options, Simple installation, Efficient design, Marine/ Automotive

Features:

  • 19mm diameter panel cutout
  • Variety LED option
  • Dot, ring or power symbol illumination available
  • Multiple actuator options
  • Pilot indicator option
  • IP65 rated,
  • Momentary Off-(On), Latching Off-On
  • Simple installation
  • Efficient design
  • Marine/ Automotive

Specifications

  • Electrical Rating: 21A, 24VDC
  • Mechanical Life: 1,000,000 Cycles
  • Electrical Life: 50,000 Cycles
  • Contact Resistance: 50mΩ Max.
  • Insulation Resistance: 1000 MΩ Min.
  • Dielectric Strength: 2,000VAC
  • Operating/Storage Temperature: -20°C to 55°C
  • Travel: 1.50mm
  • Moisture Protection: IP65
  • Actuation Force: 4N
  • Panel Thickness: 1-11mm
  • Mounting Nut Torque: 5-14Nm

High Current Anti-vandal switch

Download DownLoad(1MB)
