Custom 12mm Panel Mount Piezo Switches
Langir’s custom 12mm piezo switches are compact, solid‑state panel mount push buttons engineered for long‑term reliability in harsh environments. Featuring IP68/IP69K waterproof sealing, 316L stainless steel construction, and a 12mm panel hole footprint, these switches are ideal for industrial controls, medical devices, marine equipment, and outdoor enclosures where space is limited but durability and maintenance‑free operation are critical.
Get Custom Quote
Compact 12mm panel mount design
Fits into tight front panels and instrument layouts while remaining easy to press and intuitive for users.
No moving parts, no wear
Solid‑state piezo actuation ensures tens of millions of actuations without mechanical contact degradation.
IP68/IP69K waterproof & dustproof
Sealed to resist submersion and high‑pressure cleaning, ideal for medical, marine, food processing, and outdoor kiosks.
316L stainless steel housing
Superior corrosion resistance for salt‑spray, chemicals, and humid environments, with a clean, professional appearance.
Custom LED illumination & symbols
Ring‑style or symbol‑style LEDs with multiple colors and brightness levels enhance visibility and user experience.
OEM‑ready for global production
Supports low‑volume sampling and high‑volume manufacturing with stable lead times and global logistics.
Make Your 12mm Piezo Switch Work for Your Panel and Brand
Langir keeps the 12mm panel hole size fixed while giving you deep control over appearance, function, and integration.
12mm Panel Mount & Mechanical Fit
Housing Material & Finish
Illumination & Symbol Options
Electrical & Functional Behavior
Connectors & Wiring
12mm Panel Mount & Mechanical Fit
- Designed for 12mm panel cutouts with tight CNC tolerances.
- Threaded M5 or M6 mounting options (or snap‑in) for different panel thickness and installation methods.
- Consistent mounting depth and actuation height for predictable panel layouts.
Housing Material & Finish
- Standard 316L stainless steel for maximum corrosion resistance; optional 304 or aluminum upon request.
- Brushed, polished, or matte metallic finishes for industrial, medical, or consumer‑style equipment.
- Optional anti‑fingerprint or hard‑anodized coatings for extra protection and cleaner appearance.
Illumination & Symbol Options
- LED ring‑style illumination around the 12mm button for clear visual feedback.
- Single‑color or multi‑color options (e.g., red, green, blue, white, orange).
- Custom‑engraved icons or text (power, enter, menu, alarm, etc.) for intuitive operation and OEM branding.
Electrical & Functional Behavior
- Typical operating voltage range 3–24 V DC, with options for higher voltages on request.
- Output modes: momentary, latching, or pulse‑output, depending on your PLC or relay logic.
- Customizable sensitivity and actuation force for gloved‑hand or light‑touch scenarios.
Connectors & Wiring
- Solder‑cup terminals, screw terminals, or flying leads for easy cabinet integration.
- Waterproof M‑type or molded cable connectors suitable for outdoor or marine installations.
- Custom wire lengths and color codes to match your panel wiring diagrams.
Why Langir is Your Go-to Choice
Durable, IP‑rated control for compact panels
Langir’s custom 12mm piezo switches combine solid‑state piezo technology with a compact 12mm panel footprint, ideal for devices where space is limited but performance cannot be compromised. Sealed to IP68/IP69K, the switches resist dust, water, and high‑pressure cleaning, making them suitable for medical carts, food processing machines, marine control panels, and public‑use kiosks. The 316L stainless steel housing adds corrosion resistance for salt‑spray and humid environments.
Engineered for tight, dense layouts
The 12mm cutout size fits easily into crowded control panels, handheld devices, and compact enclosures. Precision machining ensures a consistent fit across thousands of panels, reducing assembly issues and rework. The flat, sealed surface not only supports frequent cleaning but also gives panels a clean, modern look that matches today’s industrial and medical equipment designs while maintaining a familiar push‑button user experience.
Hygienic, easy‑to‑clean front‑panel solution
Because the 12mm piezo switch has no moving parts or gaps, the sealed surface prevents dirt, liquid, and contaminants from entering the button area. This is especially valuable in medical, laboratory, and food‑processing applications where hygiene and regular disinfection are required. The 316L stainless steel construction further enhances clean‑room compatibility and long‑term surface stability.
Ready for OEM integration and global production
Langir builds each 12mm piezo switch with batch‑to‑batch consistency in mind, using ISO‑style quality control, life‑cycle testing, and functional inspection. From prototypes to mass production, we support OEMs with fast lead times, standardized electrical interfaces, and scalable quantities. This makes our 12mm piezo switches a dependable, long‑term component in equipment lines sold worldwide.
From 12mm concept to mass‑ready panel buttons
Langir’s process ensures your 12mm piezo switches are engineered for reliability, repeatable production, and easy integration.
1. Technical consultation & panel review
We start by reviewing your panel layout, 12mm mounting style, voltage, output type, and LED preferences. This helps us design a switch that fits your panel thickness, wiring constraints, and user‑interface requirements.
2. 3D design & sample production
After the technical proposal, we create a 3D‑compatible model and produce physical samples. You can test fit, actuation feel, LED visibility, and sealing performance before committing to volume production.
3. Precision machining & surface treatment
The 12mm housing is machined from 316L stainless steel or alternative materials, then finished with brushing, polishing, or anodizing. Custom engraving or laser‑marking for logos and icons is applied at this stage for branding and function clarity.
4. Assembly, sealing & electrical testing
The piezo element, LED module, and terminals are assembled into the 12mm housing and sealed to IP68/IP69K standards. Each unit is tested for actuation, sealing, and electrical function to ensure reliability.
5. Volume production & global delivery
After approval, we shift to full‑scale production with quality inspection, serialized tracking, and packaging tailored to your shipment needs. Our logistics network supports worldwide delivery so your 12mm piezo switches arrive on time for assembly.
FAQs
These switches are ideal for medical devices, industrial control panels, vending machines, marine equipment, and public‑use terminals. Their compact size and sealed construction make them suitable for high‑touch, high‑cleaning, or high‑corrosion environments.
Langir’s 316L 12mm piezo switches are rated to IP68/IP69K, meaning they are dust‑tight and can withstand continuous immersion in water as well as high‑pressure, high‑temperature washdown. This level of protection is ideal for medical, food processing, and marine applications.
316L stainless steel offers superior corrosion resistance compared with standard 304, especially in salt‑spray, humid, and chemically aggressive environments. It is commonly used in marine, offshore, and medical equipment where long‑term appearance and durability are critical.
Yes. The solid‑state design and sealed construction mean there are no mechanical contacts to wear out or clean. With proper installation, these switches can operate reliably for tens of millions of cycles without servicing.
Field experience from OEMs shows that Langir 12mm piezo switches typically exceed tens of millions of actuations and maintain consistent performance for many years in industrial and medical equipment.
Yes. We offer multiple LED colors (red, green, blue, white, orange, etc.) and adjustable brightness levels so the button visibility matches your environment and panel design.
Absolutely. We provide laser‑engraved icons, text, and logos on the 12mm surface so your switches reflect your brand and improve user guidance on multi‑function panels.
Yes. Langir is set up for industrial‑scale OEM supply, including low‑volume sampling and high‑volume production runs. We maintain strict quality control to ensure part‑by‑part consistency.
The 12mm size is standard for many compact panels where multiple functions must fit in a small area. If you share your panel thickness and available cutout space, we can confirm whether 12mm is optimal for your design or if a different size may be better.
Please tell us your preferred 12mm mounting style, voltage, LED color, and approximate annual quantity. We will send a technical proposal, material options, and sample information to help you move toward integration and testing.
