Square bezel anti-vandal switch

The L19S and L22S provides a unique aesthetic feature of a 25mm square bezel over the standard round bezel. The panel cut-out size is 19mm and 22mm diameter and it provides IP65 rating for dust and moisture protection. It offers multiple options such as ring illumination, 1NO1NC or 2NO2NC circuits, stainless steel housing material, and many LED color options which also includes an RGB LED option. The switch is also available in either a momentary or a latching function and can also be supplied with laser etched power symbol. There is also the option to add wire leads for your convenience.

Clearaudio ELECTRONICS Successful Solutions

The capacitive switch successfully applied to ClearAudio ELECTRONICS series

What Is a Touch Switch? What You Should Know

Switches are used in countless electronic devices, ranging from lamps and overhead light fixtures to TVs, computers and more. By definition, a switch is an electrical component that’s used to control a circuit. When the switch is pressed, the circuit closes. When the switch is released, the circuit reverts back to its open state. There are different types of switches, however, one of which is a touch switch.

Super short Capacitive switch

Available with diameter from 16 to 25mm bushing, CP series sensory switches are extremely easy to use and ideal for repetitive applications (no operating force). Their IK10 robustness and unlimited life are perfect for self-service applications.

What Is an Actuator in an Electrical Switch?

Electrical switches are used in a variety of electronics and devices. As you may already know, their primary purpose is to control the flow of electrons in a circuit. Switches contain two modes: closed and off. When the switch is closed, the circuit is complete, thereby allowing electrons to flow. When it’s open, the circuit is broken and the electrons are interrupted. An essential component used in electrical switches, however, is an actuator.

5 Reasons to Choose a Capacitive Switch

If you’re looking to buy a switch — whether it’s for a human machine interface (HMI), industrial equipment controls, a remote controller, etc. — you should consider choosing a capacitive switch. Using the same capacitive technology as touchscreen tablets and smartphones, it’s a unique alternative to traditional dome switches. With dome switches, physical contact between the key and an underlying circuit trace is needed to register a keypress. Capacitive switches differ in the sense that they identify keypresses via the user’s touch. So, why should you choose a capacitive switch?

Capacitive vs Mechanical Switch: What’s the Difference?

Switches are the foundation on which electrical devices, including touchscreens, operate. In the most basic sense, a switch is a component that controls an electrical circuit. When the switch is turned on, the electrical circuit is closed and, thus, complete. When the switch is turned off, the electrical circuit is open and, thus, incomplete. While all switches perform this operation, though, there are different types of switches, including mechanical and capacitive.

What is a Capacitive Switch and How Does it Work?

A capacitive switch is a type of touch-controlled electrical switch that operates by measuring change in capacitance. It works in the same manner as a typical capacitive smartphone: when you touch the surface — assuming you aren’t wearing gloves — a small electrical charge is transferred from your body to the switch, which subsequently causes a change in capacitance. The switch detects this change, responding with the appropriate command.

Illuminations switch how do self control LED?

When the switch used in not control circuit, and want the LED with switch ON/OFF, This circuit will be well for your.

The Switch Competitive Comparison

The switch offer attractive, robust and durable switch, available with different bushing diameters(12 ~25mm), actuator shapes, available with LED illumination and engraving, Protection IP65 / IK09.
This switch features a easy clean, aesthetic look for high end products.

High Current Anti-vandal switch for Marine and Automotive

19mm diameter panel cutout, Max. rating 21A24VDC, Long life, High reliability, Anti-Vandal IK09/ Sealed IP68, Dot, Ring or Power symbol illumination available, Multiple actuator options

What’s the difference between an Alternate action and a Momentary?

What’s the difference between an Alternate action and a Mometary?
The method that keeps the ON state of a switch only when its button is pressed and held is referred to as the “momentary” method, while the method that keeps the ON state of a switch even after the button is pressed and then released is referred to as the “alternate” method.
